1t Per Day Small Apple Juice Processing Line With Pet Bottle Packing
| No | Machine | Specification | Technical Parameter | Unit | Qty |
| 1 | Bubbling, floating washing and lifting machine | ADK-QX100 | Main body of the equipment: 304 stainless steel Processing capacity: 100 kg/hour 1.1kw high-pressure bubbling fan starts directly, a lifting motor is about 0.75KW, a circulating water pump is about 1.1KW, and the cleaning water consumption is about: 0.5m³/H, the frame is welded by 304 square tube with 3mm thickness, the chute is welded by 304 stainless steel 2B plate, and each bubbling spray pipe is welded by 304 stainless steel food tube.The spray pipe length reaches 600mm each. The fruit feeding side is equipped with a flushing pipe. The lifting section is equipped with a tap water spray cleaning device. | Set | 1 |
| 2 | Crushing, screw juicer | ADK-ZZ200 | 304 stainless steel Processing capacity: 100~200KG/H Screw speed:400RPM Screen aperture:0.5MM Compression ratio:1:20 Power:3.5KW | Set | 1 |
| 3 | Stock chute | ADK-HC50 | Main body : 304 stainless steel Effective volume: 50L The tank is equipped with a liquid level gauge, with a removable cover, and the external welding seam is polished to 300 mesh. | Set | 1 |
| 4 | Centrifugal pump | YAH-1-20 | Main body: 304 stainless steel Flow rate : 1T/H Head: 20M Power: 0.75KW | Set | 1 |
| 5 | tubular preheater | ADK-YR100 | Main body: 304 stainless steel Processing capacity : 50~100KG/H Feed temperature : 25℃, the material is preheated to: 55-65℃. The inlet and outlet of the equipment are equipped with PT100 temperature sensor and digital display temperature meter. The machine is equipped with stop valve and steam trap , using direct steam heating. Size of the equipment: 1300x600x400mm | Set | 1 |
| 6 | Double-layer enzymolysis tank | ADK-MJ100 | Effective volume : about 100L Main body: 304 stainless steel, the double-layer structure, plus polyurethane insulation. The tank is equipped with a baffle and an anti-vortex structure, its inlet and outlet diameter is Φ25, with a liquid level window, a temperature display table, and a closed sampling valve structure. The thickness of the plate is 3mm/1.5mm, The speed/power speed of stirring is 50 rpm and the power of the stirring motor is 0.37KW. The welding seam is polished to 300 mesh. The tank is equipped with CIP spray cleaning ball. Machine dimension: Φ600×900mm | Set | 1 |
| 7 | Centrifugal pump | YAH-1-20 | Main body:304 stainless steel Flow rate: 1T/H Head: 20M Power: 0.75KW | Set | 1 |
| 8 | Duplex Filter | ADK-GL200 | The shell is made of 304 (American Standard 304) stainless steel,
the filter element can be replaced, the filter element is filtered. Maximum operating pressure : 0.5Mpa Operating environment PH value is 1-14. Sealing is food-grade silicone rubber, the sealing material: EPDM. Inlet and outlet diameter: 1 ” Filtration precision: 80~100 mesh | Set | 1 |
| 9 | Butterfly Centrifuge | Lvzhou/230 | Water flow 1000L/H Inlet pressure 0-0.1MPa Outlet pressure 0.1MPa Speed 6930R/min Power 2.2KW Slag cleaning manual | Set | 1 |
| 10 | Buffer tank | ADK-HC100 | Main body : 304 stainless steel Effective volume : about 100L Inlet and outlet diameter : Φ25mm Equipted with a liquid level window,a temperature display table. The sampling valve structure is enclosure. Thickness of the plate: 3mm, the welding seam is polished to 300 mesh. The tank is also equipped with CIP spray Cleaning ball and liquid level gauge. Equipment size: Φ550×900mm | Set | 1 |
| 11 | Centrifugal pump | YAH-1-20 | Main body:304 stainless steel Flow rate : 1T/H Head: 20M Power: 0.75KW | Set | 1 |
| 12 | Plate and Frame Filter | ADK-BK100 | The filter area is 2 square meters, the frame size is 400*400mm, manual hydraulic | Set | 1 |
| 13 | Clear Juice Jar | ADK-QZ100 | Main body: 304 stainless steel Effective volume : 50L Inlet and outlet diameters : Φ25mm There is a liquid level viewing window, the temperature display table. The sampling valve structure is enclosure. Plate thickness is 3mm, the welding seam is polished to 300 mesh. Also the tank is equipped with spray cleaning ball and liquid level gauge. Size:about Φ500×800mm | Set | 1 |
| 14 | Control system for pre-processing unit | ADK-HZ1001 | Stainless steel standard control cabinet, buttons, pneumatic components, low-voltage electrical components, intermediate relays, etc. | Set | 1 |
|
|
